Try the terminal UI demo

Mango includes a reference terminal UI that exercises the HTTP and event-stream APIs as an interactive client. It shows durable Sessions, streaming Agent output, child Threads, action gates, and lifecycle operations in one place.

The UI is an executable demo rather than a supported operator console or a stable client API. Its source lives in an isolated Go module under examples/terminal-ui, so terminal-specific dependencies do not become dependencies of the Mango server.

Mango terminal UI example

Run without a server​

The built-in demo is the fastest way to explore the interface. From the Mango repository root:

cd examples/terminal-ui
go run ./cmd/mango-tui --demo

The in-memory backend uses the same UI commands and state projection as the HTTP client. It includes a coordinator, two child Agents, delegation and tool events, and a child-owned permission gate.

Connect to the local stack​

First complete Getting started and leave the local stack running. Then launch the terminal UI from examples/terminal-ui:

MANGO_API_KEY=sk-mango-local-development \
  go run ./cmd/mango-tui

The client defaults to http://127.0.0.1:8080. To select another control plane or attach directly to an existing Session:

MANGO_URL=https://mango.example.com \
MANGO_API_KEY=your-key \
  go run ./cmd/mango-tui -- attach sesn_...

The equivalent flags are --url and --api-key. Credentials in endpoint URLs are rejected, and API keys are not persisted by the client.

The bearer key selects the Mango Workspace for every request; the client does not send or persist a separate Workspace ID. Restart the example with a key for another Workspace to switch resource scopes.

The connection screen shows discovered local and remembered endpoints. Select Enter another endpoint… or press e to enter a different URL with the Bubble Tea input control.

What the example demonstrates​

  • Gap-free attach by opening every Thread stream before loading durable event history.
  • Reconnection of the whole Thread roster when one stream ends or a new child Thread appears.
  • A pure event-ledger projection shared by wide and compact terminal layouts.
  • Session creation, rename, archive, delete, interrupt, and action-response flows against one backend interface.
  • An in-memory backend for product review and UI regression without running a Mango deployment.

See the example's ARCHITECTURE.md for the protocol and rendering boundaries.

Verify changes​

From the repository root, run:

make terminal-ui-verify

This runs the example's unit tests, race tests, vet checks, and build. The same target runs in the repository CI so API and example changes are reviewed together.
